Item Qty Part Number Description
1 1 K94009 Welded Dash Assembly
2 1 K94067 Bonnet Catch
3 1 410-000-048 Hour Meter
4 1 K94043 Left Hand Handle Bar
5 1 K94044 Right Hand Handle Bar
6 2 043-000-043 Handle Grip
7 1 511-000-012 Throttle Cable Assembly
8 4 132-151-000 Spring Lock Washer M12
9 4 111-511-025 Hex Bolt M12 x 25
10 4 111-211-020 Hex Bolt M6 x 20
11 2 122-121-000 Nyloc Nut M6
12 1 021-000-024 Compliance Plate
13 4 100-000-027 Type U Drive Screws 6 x 1/4” ZP
14 1 K94355 Pre Cleaner Assembly
15 1 111-311-060 Hex Bolt M8 x 60
16 1 122-131-000 Nyloc Nut M8
17 1 410-000-119 Fuse Block - 4 Blade With Cover (Early)
17 1 410-000-154 Fuse Block - 4 Blade With Buzz Bar (Late)
18 1 . Fuse Block Top
19 2 410-000-120 15 Amp Fuse
20 2 100-000-061 M6 Button Head Screw
21 2 131-121-001 Plain Washer M6
22 2 132-211-000 Spring Lock Washer M6
23 1 410-000-059 40 Amp 5 Pin Fan Relay
