Dingo K9-4 Operation & Maintenance Manual
23
Item Qty Dingo Part No Description
1 4 610-000-031 Wheel Hub 1 3/8” Centre
2 4 613-000-017 Dingo Tyre Trelleborg
3 20 610-000-030 Wheel Stud 7/16” x 1 7/8” UNF
4 4 330-001-007 Nyloc Patch Nut
5 4 330-001-006 Hydraulic Wheel Motor 1 3/8” Shaft
6 4 330-006-029 K94 Wheel Motor O-Ring
7 20 610-000-027 Wheel Nut 7/16” UNF
8 1 330-003-004 Over Centre Valve
9 12 316-797-500 Hydraulic Fitting (C3-1414)
10 4 316-757-500 Hydraulic Fitting (ZC2-1414)
11 2 K94419 Pipe - Wheel Motor Front To Rear (C5)
12 1 K94416 Pipe - Wheel Motor Front Right Top (C2)
13 1 K94418 Pipe - Wheel Motor Front Left Top (No Relief) (C4)
14 1 K94417 Pipe - Wheel Motor Rear Left Top (No Relief) (C3)
15 1 K94415 Pipe - Wheel Motor Rear Right Top (C1)
16 16 113-522-032 Socket Head Cap Screw-UNC 1/2” x 2”
17 2 310-797-600 Hydraulic Fitting (C26-1414)
18 2 330-003-068 Wheel Motor Relief Valve
19 1 K94436 Pipe - Wheel Motor Rear Left Top (With Relief Valve)C3
20 2 315-797-500 Hydraulic Fitting (C59-1414)
21 1 K94437 Pipe - Wheel Motor Front Left Top (With Relief Valve)
