Dingo K9-4 Operation & Maintenance Manual
25
Item Dingo Part No Description
1 1 330-003-008 Main Control Bank
2 2 K94485 Short Handle (Lift) K94486 (Crowd)
3 2 330-003-031 Long Handle
4 4 316-375-502 Hydraulic Fitting (CR2-0609)
5 4 316-377-501 Hydraulic Fitting (CR2-0614)
6 1 . Blanking Plug 3/8”
7 1 . Blanking Plug 1/2”
8 4 121-131-000 Hex Nut M8
9 3 111-311-060 Hex Bolt M8 x 60
10 5 122-131-000 Nyloc Nut M8
11 2 K94435 30mm Spacer
12 1 330-003-035 Pump Selector - SD4
13 1 330-003-052 Flow Control Valve
14 1 K94033 Immobiliser Assembly
15 1 314-374-800 Hydraulic Fitting (CR24-0608)
16 2 111-311-085 Hex Bolt M8 x 85
17 1 315-337-370 Hydraulic Fitting (ZCP53-0606)
18 1 331-203-002 In-line Check Valve (SNDR-061-BP05)
19 2 316-374-700 Hydraulic Fitting (ZCR1-0608)
20 1 K94414 Pipe - Pump Selector To Remote Bank (AP)
21 2 315-477-500 Hydraulic Fitting (CP56-0814)
22 1 K94413 Pipe - Main Bank To Dump (CD)
23 1 317-769-575 Hydraulic Fitting (ZC64-141714)
24 1 316-476-501 Hydraulic Fitting (CR2-0812)
25 1 330-003-018 Flow Control Handle
26 1 K94427 Pipe - Remote Bank to Aux (A3)
27 1 K94428 Pipe - Remote Bank to Small AUX (A4)
28 1 K94426 Pipe - Remote Bank To Aux (A2)
29 1 K94425 Pipe - Remote Bank To Large Aux (A1)
30 1 K94429 Pipe - Main Bank To Crowd Ram Short Hose (T1)
31 1 K94430 Pipe - Main Bank To Crowd Ram Long Hose (T2)
32 4 316-555-500 Hydraulic Fitting (C2-0909)
33 1 K94481
Remote Handle straight
34 2 330-000-018 15mm Hose Clamp Block
35 1 330-000-016 15mm Hose Guide Plate
36 1 K94411 Pipe - Flow Control To Remote Bank (EX)
37 1 K94412 Pipe - Pump Selector To Flow Control (FP)
38 2 317-565-555 Hydraulic Fitting (C64-090909)
39 2 316-477-501 Hydraulic Fitting (CR2-0814)
40 1 316-754-700 Hydraulic Fitting (ZCR2-1408Z)
41 1 K94440 1/4” Hyd-Hose RH Ram Bottom To Control Bank Top (520mm)
42 1 K94441 1/4” Hyd-Hose RH Ram Top To Control Bank Bottom (430mm)
43 1 K94442 1/4” Hyd-Hose LH Ram Bottom To Control Bank Top (395)
44 1 K94443 1/4” Hyd-Hose LH Ram Top To Control Bank Bottom (355mm)
45 1 K94448 1/4” Hyd-Hose Crowd Ram Bottom To Front Fitting (1590mm)
46 1 K94449 1/4” Hyd-Hose Crowd Ram Top To Rear Fitting (1500mm)
47 1 K94450 1/2” Hyd-Hose 1/2” Female Quick Release To Fitting (1150mm)
48 1 K94451 1/2” Hyd-Hose 1/2” Male Quick Release To Rear Fitting (1180mm)
49 1 K94452 1/4” Hyd-Hose 3/8” Female Quick Release To Front Fitting (1105mm)
50 1 K94453 1/4” Hyd-Hose 3/8” Male Quick Release To Rear Fitting (1130mm)
51 1 K94462 3/8” Hyd-Hose Rear Pump To Rear Selector Valve (Diesel) (685mm)
51 1 K94466 3/8” Hyd-Hose Rear Pump To Rear Selector Valve (Petrol) (650mm)
52 1 K94463 1/2” Hyd-Hose Front Pump To Front Selector Valve (Diesel) (610mm)
52 1 K94469 1/2” Hyd-Hose Front Pump To Front Selector Valve (Petrol) (550mm)
To Next Page
