Dingo K9-4 Operation & Maintenance Manual
45
Yanmar Motor Assembly Series I
Item Qty Dingo Part No Description
41 1 K94-314 Engine To Top Radiator Bracket
42 1 K94-311 Top Radiator Support
43 . . .
44 . . .
45 1 315-477-500 Hydraulic Fitting (CP56-0814)
46 1 319-381-800 Hydraulic Fitting (CP60-1616)
47 1 315-476-500 Hydraulic Fitting (CP56-0812)
48 1 100-000-063 Hose Clamp 2 1/4”
49 1 100-000-064 Hose Clamp 2 3/4”
50 4 100-000-062 Hose Clamp No16 21-38mm
51 .
52 1 518-000-011 Thermostat
53 1 518-000-012 Thermostat Housing Gasket
54 . . .
55 3 131-231-001 Flat Wide Washer 3/8” x 1 1/4” x 16G
56 3 111-411-055 Hex Bolt M10 x 55
57 37 132-141-000 Spring Lock Washer M10
58 40 111-411-020 Hex Bolt M10 x 20
59 3 131-131-000 Plain Washer M8
60 3 132-131-000 Spring Lock Washer M8
61 11 111-311-020 Hex Bolt M8 x 20
62 3 111-522-030 Socket Head Cap Screw M12 x 30 (Locktited)
63 4 111-311-030 Hex Bolt M8 x 30
64 4 518-000-032 M10 x 50mm Stud
65 4 121-142-000 Hex Nut M10
66 4 122-141-000 Nyloc Nut M10
67 1 111-311-070 Hex Bolt M8 x 70
68 7 122-131-000 Nyloc Nut M8
69 8 131-141-000 Plain Washer M10
70 4 518-000-021 M8 x 60mm Stud
71 . . .
72 . . .
73 . .
.
74 4 513-000-073 Hex Flange Nut M8
75 . . .
76 2 111-311-016 Hex Bolt M8 x 16
77 1 K94-462 3/8” Hyd-Hose Rear Pump To Rear Selector Valve
78 1 K94-463 1/2” Hyd-Hose Front Pump To Front Selector Valve
79 1 K94-464 1” Hyd-Hose Suction (535mm)
80 2 300-000-006 Hose Clamp 34mm
81 1 518-00-008 Dynamo
82 1 311-330-000 Fitting (ZCMB73-2206)
83 1 319-333-420 90° Brass Fitting
84 1 345-400-000 1/2” Ortac Hose Oil Drain Hose
85 1 319-160-400 Hose Tail Fitting (JIC 3DK21) (LFJ1208)
86 1 312-650-000 Hose End Fitting (C78-12)
To Next Page
