Dingo K9-4 Operation & Maintenance Manual
46
Dingo K9-4 Operation & Maintenance Manual
47
Yanmar Motor Assembly Series II
Item Qty Dingo Part No Description
5 1 518-000-007 Start Motor
6 1 330-002-002 Hydraulic Pump TNE 9/4cc
6 . 330-002-007 Hydraulic Pump TNV 11.2/4cc
7 1 K94-325 Cast Bell Housing
8 1 K94-326 Fly Wheel Coupling
9 1 330-005-009 Pump Coupling
10 1 330-005-014 Spider
11 1 K94-332 Air Cleaner Bracket Assembly TNE
11 . K94-382 Air Cleaner Bracket Assembly TNV
12 1 518-000-019 Fan Belt
13 1 518-000-036 Water Pump
. 1 518-000-035 Water Pump Gasket
. 1 518-000-034 Water Pump O-ring
14 1 518-000-009 Fan
15 1 K94-321 Throttle Cable Bracket
16 1 518-000-002 Yanmar Oil Filter
17 1 518-000-039 Oil Filler Cap
. 1 518-000-040 Oil Filler Cap O-ring
18 2 K94-300a
ENG MOUNT REAR - REAR OF ENG TO CHASSIS
19 1 K94-301b ENG MOUNT REAR - RH LOWER CHASSIS TO ENG
20 1 K94-302b ENG MOUNT REAR - LH LOWER CHASSIS TO ENG
21 1 518-000-068 Fuel Filter Assembly
22 1 518-000-018 Fuel Filter Element
. 1 518-000-016 Fuel Filter Bowl O-ring
. 1 518-000-015 Fuel Filter Bowl
23 1 515-000-036 Full Air Cleaner Assembly
24 1 515-000-045 Air Cleaner Ring Assembly
25 1 515-000-034 Small Air Cleaner Element Inner
26 1 515-000-033 Large Air Cleaner Element Outer
27 1 . Plastic Outer Casing For Air Cleaner
28 1 550-000-034 Air Cleaner Pipe From Air Cleaner To Motor
29 1 043-300-005 Pump Cover
30
1 K94-337 Radiator Support Assembly (Series II) TNE
30 . K94-387 Radiator Support Assembly (Series III) TNV
31 1 518-000-051 Radiator (Series II)
32 1 518-000-020 Radiator Cap
33 1 K94-347 Split Fan Shroud Top Half
34 1 K94-348 Split Fan Shroud Bottom Half
35 1 K94-344 Mufer Bracket
36 1 518-000-050 Top Radiator Hose (Series II)
37 1 518-000-049 Bottom Radiator Hose (Series II)
38 1 518-000-042 Berklee Mufer (Series II) TNE
39 1 518-000-022 Yanmar Exh Gasket
40 1 K94-336 Pre Cleaner Tube
41 1 515-000-048 Pre-Cleaner Clamp 2 3/8” Exhaust Clamp
42 1 515-000-047 Turbo Pre-Cleaner
