4
NOTE FOR THE TECHNICIAN:
Please take note that when the (USER MAN.REF.) is mentioned, this refers to the user manual.
!!WARNING!!
For the ATEX weight indicator version it is COMPULSORY to read and understand the ATEX
ATTACHMENT in the end of the user manual (USER MAN.REF.) containing important warnings.
1. REQUIREMENTS FOR AN OPTIMAL INSTALLATION
To obtain the best results it is recommended to install the indicator and the platform (or transducer) in a place with
the following conditions:
A flat, level surface on which to rest
Stable and vibration free
No dust or strong vapours
No draughts
Make sure the platform is level or that the loading cells are resting evenly
Moderate temperature and humidity (15 - 30°C and 40-70%)
Do not install anywhere where there is the risk of explosion
All the indicator connections have to be made respecting the rules applicable in the zone and in the
installing environment. Respect the recommended electrical precautionary measures described in section
1.1.
Make sure that the grounding is made correctly, see section 1.2.
Everything not expressly described in this manual has to be considered as improper use of the equipment.
Avoid welding with load cells installed.
Use waterproof sheaths and couplings in order to protect the load cell cables.
Use a waterproof junction box to connect the cells.
