Dino-Power X24 User Manual

Problem
Cause
Solution
Sprayer draws up paint but
drops away when gun is
opened
Worn spray tip
Replace with new tip.
Suction set filter clogged
Clean filter.
Gun or spray tip filter plugged.
Clean or replace filter. Keep extra
filters on hand
Paint too heavy or coarse.
Thin or strain paint
Worn V-packing
assembly.
Replace
Inlet valve worn or damaged.
Replace valve
Tip assembly leaks
Assembled incorrectly
Check assembly.
Worn seal.
Replace seal.
Spray gun won't spray
Spray tip, gun filter or
tip clogged
Clean spray tip
filter plugged
Clean or replace gun or filter.
Spray tip in Clean position
Put tip in Spray position
Paint tailing.
Pressure is set too low.
Increase pressure
Gun, tip, or suction
filter plugged.
Clean filters
Suction tube loose
Tighten suction tube fitting
Tip worn.
Replace tip
Paint too thick
Thin paint
Thermal overload tripped
Motor over heated.
Allow to cool 15 to 30 min.
Paint build up on motor.
Clean paint from motor.
Unit sitting in hot sun.
Move to a shady location
No display,
sprayer operates.
Display is damaged or had bad
connection.
Check connection, replace display
Display error code E4
Description:Over-current protection
for the electronical control board
Possible Reason:
1.Too low voltage, too long cable
length, bad contact of the patch
board.
2.Using too small tip size.
3.Coatings is too thick.
4.Pressure sensor is damaged, too
1.Check if the voltage reaches 220V, check
if the cable length is too small, check if the
patch board is properly connected.
2.Change bigger tip size.
3.Thin the coatings as per instruction.
4.Change the pressure sensor.
5.Change the electronical control board.
