Parts List
X45 Motor Cover& accessories
NO.
Series NO.
Description
Qty
NO.
Series NO.
Description
Qty
1
X45801
Drain hose
1
7
X45707
Drain line clip
1
2
X45602
Motor cover
1
8
X45608
Screw
4
3
X45803
Screw
2
9
X45609
Gasket
2
4
X45804
Hose
1
10
X45610
Front cover
1
5
X45805
Suction tube
1
11
X45611
Pump rod cover
1
6
X45806
Suction filter
1
12
X45612
Screw
2
