Parts List
X45 Cart assembly
NO.
Series NO.
Description
Qty
NO.
Series NO.
Description
Qty
1
X45701
Cart
1
5
X45705
Nut
2
2
X45702
Tubing plug
2
6
X45706
Gasket
2
3
X45703
Screw
4
7
X45707
Tire connecting rod
1
4
X45704
Handle assembly
1
8
X45708
Wheel
2
