Dino-Power X24 User Manual

Parts List
15
X45515
Plastic Cover
1
35
X45535
Screw
1
16
X45516
Pin
1
36
X45536
Base
1
17
X45517
Pin
1
37
X45537
Bridge
1
18
X45518
Prime Valve Knob
1
38
X45538
Screw
1
19
X45519
Cam Base
1
39
X45539
Washer
1
20
X45520
Washer
1
40
X45540
Flange
1
X45 Fluid pump
No.
Series No.
Description
Qty
No.
Series No.
Description
Qty
1
x45101
Nut, packing
1
13
x45113
Valve, piston
1
2
x45102
Seal
1
14
x45114
Ball guide
1
3
x45103
V-packing, throat
2
15
x45115
Ball, big
1
4
x45104
Gland, female
1
16
x45116
Carbide seat
1
5
x45105
Cylinder
1
17
x45117
Intake valve
1
6
x45106
Outlet connector
1
18
x45118
O-ring
1
7
x450107
Piston rod
1
19
x45119
O-ring
1
8
x45108
Gland, male
1
20
x45120
Washer
1
9
x45109
V-packing, piston
3
21
x45121
V-packing, leather, piston
2
10
x45110
Gland, piston
1
22
x45122
O-ring
1
11
x45111
Gland, piston
1
23
x45123
Sleeve, Cylinder
1
12
x45112
Ball, small
1
24
x45124
V-packing, throat
3
