X51L Electric Pressure Control Board
No.
Series No.
Description
QTY
1
X51201
COVER, waterproof
1
2
X51202
PCB, Control Board
1
3
X51203
COVER, control
1
4
X51204
DIGITAL DISPLAY BOARD
1
5
X51205
SCREW
4
6
X51206
POWER CODE
1
7
X51207
POTENTIOMETER, adjust pressure
1
8
X51208
KNOB, potentiometer
1
9
X51209
ON/OFF SWITCH
1
10
X51210
SCREW
1
11
X51211
WIRE
2
12
X51212
SCREW
2
13
X51213
GASKET
2
14
X51214
TRANSDUCER
1
