X51L Motor Assembly
No.
Series No.
Description
QTY
1
X51301
FAN, motor
1
2
X51302
MOTOR, 3000W Brushless
1
3
X51303
BEARING
1
4
X51304
GEAR
1
5
X51305
GASKET
2
6
X51306
PIN
2
7
X51307
GEAR BOX
1
8
X51308
ECCENTRIC SHAFT
1
9
X51309
BEARING
1
10
X51310
GASKET
1
11
X51311
BEARING
1
12
X51312
GASKET
2
13
X51313
BEARING
1
14
X51314
GEAR
1
15
X51315
NUT
4
16
X51316
GASKET
5
17
X51317
SCREW
4
18
X51318
HANGER, pail
1
19
X51319
GASKET
2
20
X51320
SHIELD, pump rod
1
