X80L Motor Assembly
No.
Serial No.
Description
Qty
No.
Serial No.
Description
Qty
1
X80301
Motor Assembly
1
5
X80305
Nut
4
2
X80302
Long Screw
6
6
X80306
Stem Nut
4
3
X80303
Washer
1
7
X80307
Screw
4
4
X80304
Short Screw
1
8
X80308
Washer
4
