Unpacking the Tablet Connectivity Kit
Unpack the Tablet Connectivity Kit (P/N 22181-62017) and verify the kit
contents (see Figure 3-40).
Reminder: The following items may have been removed from the kit in order
to install the tablet arm and tablet (see Section 3.9.3): one of the two network
USB-to-Ethernet adapters, one of the two Ethernet cables, and the USB cable.
Figure 3-40. Tablet Connectivity Kit Items Unpacked
1
2
3
4
1
5
4
3
4
2
3
5
Wireless Router (P/N 00825-01-00269)
USB-to-Network Adapter (2) (P/N 00302-99-00131)
Ethernet Cable (2) (P/N 00302-99-00129)
USB Cable (Male-to-Female) (P/N 00302-99-00130)
Power Adapter (P/N 00825-01-00269)
