3 • System Setup
Doc. 22181-97001 02/18
81
3.10.1 Installing the Router
The router should be installed as close as possible to the DC and IPC because
of the limited Ethernet cable length and wireless broadcast range.
1. Unpack the router (P/N 00825-01-00269) and the router power adapter
(P/N 00825-01-00269).
NOTE
The router is shipped with an AC power cable with a
U.S. NEMA plug. You are responsible for obtaining a
locally sourced plug adapter.
2. Each router is assigned a unique network SSID (service set identifier) and
password at the factory. The SSID and password are printed on a label on
the base of the router. Write down this information before proceeding.
3. Connect the outlet prongs of the router power adapter to an electrical
outlet near the Dionex ICS-6000 to which the tablet is attached. If the
tablet arm is not attached, see Section 3.9.2.
4. Attach the connector end of the power adapter to the router.
NOTE
If the electrical service is not 120 V 60 Hz, an AC plug
adapter (not provided with the system) is required to
plug in the router power adapter.
5. Press the ON/OFF button on the rear of the router (near the bottom) to
turn on the power.
6. Check the status of the wireless on light on the router (see Figure 3-41).
The light should be green for operation in wireless mode, and red
