Dionex ICS-6000 Installation Instructions
84
Doc. 22181-97001 02/18
3.10.3 Installing an Ethernet Tablet
The hardware installation allows the tablet to send commands through the
router to the IPC. The commands are carried out when they are received from
the router.
1. An Ethernet cable (P/N 00302-99-00129) was routed to the rear of the DC
when the tablet was cabled for the Ethernet connection (see
Section 3.9.4). Connect the free end of the Ethernet cable to any LAN
port on the rear of the router (P/N 00302-99-00131).
NOTE
Do not connect the cable to the yellow Internet port.
2. The tablet may already be installed in the tablet holder; if not, place it in
the tablet holder.
3. Connect the Ethernet cable to the tablet, if it is not already connected.
Because the tablet supplied in the Thermo Fisher Scientific tablet kit does
not have a LAN port, the Ethernet connection uses one of the USB-to-
Ethernet adapters provided in the Tablet Connectivity Kit to connect to
the tablet USB port (see Figure 3-44). If necessary, use the USB extension
cable (P/N 00302-99-00130) provided in the Tablet Connectivity Kit
between the adapter and the tablet.
