Dionex ICS-6000 Installation Instructions
70
Doc. 22181-97001 02/18
3.9.3 Routing the Tablet Power and Ethernet Cables
This section explains how to perform a partial installation of the tablet power
cable and (if required) the Ethernet cable. The connections will be completed
later in the network installation procedure.
1. Connect the tablet power cable (with the round power connector attached)
to the power port on the tablet.
NOTE
The tablet is shipped with an AC power cable with a
U.S. NEMA plug. You are responsible for obtaining a
locally sourced plug adapter.
NOTE
If a wireless tablet connection will be used, the Ether-
net cable and network adapter are not needed. The
power adapter for the tablet still must reach the tablet
in any chosen tablet arm orientation.
2. Assemble the cable(s) required to connect the tablet USB port to the
network adapter (see Figure 3-32). The parts are provided in the Tablet
Connectivity Kit (P/N 22181-62017).
a. Connect the 2 m (7 ft) Ethernet cable (P/N 00302-99-00129) to the
USB network adapter (P/N 00302-99-00131).
b. If the Ethernet cable is not long enough, connect the USB cable
(male-to-female) (P/N 00302-99-00130) to the adapter.
