15
SPECIFICATIONS
Specifications
MODEL: DIHN35-E
Exhaust Vent
Drain
Valve
Control
Noodle Basket Tray
Noodle Boiling Zone
Water
Faucet
Water Tank
Inside
Model
Watt
Voltage
Weight
Size
Heat Level
35 Kg
450 X 600 X 850 (mm)
Water Tank : Ø320 X 200 mm
DIHN35-E
3500W
10 Steps
Warm(7 Steps)
AC 208-240V 50/60Hz 1PH
Do not hit ‘mode’ button without
a temperature probe. It will show
up ‘E5’ error. Once ‘E5’ error
shows up, turn off and on the unit.
