7
ACCESSORIES
Blade protection cover 1
Chain 1
Guide bar 1
File 1
Chain adjustment & spark plug tool 1
Screwdriver 1
Use good quality accessories marked with a well-known brand name. Choose the type according to the
work you intend to undertake. Refer to the accessory packaging for further details. Store personnel can
assist you and offer advice.
TECHNICAL DATA
Engine displacement 52cc
Engine power 2.0kW
Maximum engine speed 10500/min
Idle speed 3000/min
Bar length 48cm (19”)
Chain pitch 0.325″
Chain gauge 0.058″
Chain link number 76
Volume of fuel tank 550ml
Volume of oil tank 260ml
Petrol and oil ratio 25:1
Weight with bar & chain: 6.5kg
Spark plug gap dim 0.6-0.7mm
Spark plug spec Torch L7T
Replacement
BOSCH L7T
CDK L7T
CHAMPION CJ-7Y
NGK BPM7A
