Directed Audio A404 - Page 9

99
1
2
3
4
5
FIGURE 3—AMPLIFIER CONNECTIONS A502 REAR
© 2004 Directed Electronics, Inc
1
2
3
4
5
FIGURE 4—AMPLIFIER CONNECTIONS A404 REAR
wire. DO NOT connect this terminal
directly to the vehicle battery
ground terminal or any other
factory ground points.
5.
SSppeeaakkeerr TTeerrmmiinnaallss
- Connect the
speakers to these terminals. (Refer
to the
Wiring Diagram section of
this guide.)
