Flashes Diagnostic
1 Runtime expired.
2 Over-rev shutdown.
3 Low/No RPM.
4 Transmitter shutdown.
5 Brake shutdown.
6 Hood shutdown/Remote start safety override switch is ON*.
7 Remote start safety override switch is ON*.
The parking lights on your vehicle will flash a specific number of times 3 seconds following an unscheduled shutdown or
failure to start. Each flashing pattern is described below.
* If the vehicle hood status is supported through data, safety override switch input will report 7 flashes.
Parking Light Error Codes
LED Status Description Troubleshooting
Active Ground While Running
Flashes green
GROUND OUT ON (GWR)
command received.
Otherwise, the Ground While Running (status) signal
was lost or was never received by the module.
Commands can come from RF, D2D or W2W.
Flashes red & orange
IGNITION ON command
received.
Otherwise, the ignition signal was not received by the
module. In a W2W install, it will show only if the ignition
input wire is used.
Flashes green quickly START ON command received.
Otherwise, the start signal was not received by the
module. In a W2W install, it will show only if the ignition
input wire is used.
D2D & W2W Commands
Flashes orange x1 Lock command received.
Flashes orange x2 Unlock command received.
Flashes orange x3 Trunk command received.
Flashes orange x4 Aux1 command received.
Flashes orange x5 Aux2 command received.
If the bypass module fails to flash, it means the module did
not receive the signal. Commands can come from RF, D2D
or W2W.
Flashes
Flashes
Flashes x1
Flashes x2
Flashes x3
Flashes x4
Flashes x5
Flashes
Platform: DBALL/DBALL2
Firmware: GM5 Remote Start Ready (RSR) Installation
© 2015 Directed. All rights reserved.
Rev.: 20150626
Brake Switch 2004-06
3
4
2
1
Brake Switch 2007-10
Brake Sense:
Light Blue, pin 2
OR
Passenger
Kick Panel
4
1
3
2
