DirecTV H26K User Manual

3
HARDWARE MANUAL—H26K
3. SPECIFICATIONS
A. Dimensions
i. 190x155x32mm without feet (7.5 x 6 x 1.25 in)
ii. Feet height is 6.5mm (.25 in)
B. Environmental Requirements
i. Operating temperature: 32℉ to 122℉ (0℃ to 50℃)
ii. Storage temperature (No Damage): –40℉ to 150℉
( –40℃ to 65℃)
iii. Relative humidity: 5% to 85% non-condensing
4. INSTALLATION REQUIREMENTS
A. External SWiM
i. External SWiM power
ii. Supports a wired Ethernet Internet set-up
iii. Supports HDMI or Composite connection
D.
Bottom Panel
i. VESA mounts on underside, 100mm (approximately
4 inches apart)
E. Remote Control
i. Requires RC71/RC72/RC73 remote control (IR or RF).
F. Power Supply
i. Requires EPS10 External Power Supply.
0. Frequency
ⅰ. BT/BLE: 2402MHz~2480MHz
ⅱ. RF4CE: 2425MHz~2475MHz
0. Modulation type
ⅰ.BDR/EDR: GFSK, π/4DQPSK, 8DPSK
ⅱ.BLE: GFSK
ⅲ. RF4CE: DSSS
