Air conditioning for vehicles
1- Position the evaporator unit in the most
dashboard, etc.).
2- Mark the evaporator support points.
3-
position M6 rivet nuts.
4- Secure the evaporator with (4) 6/100x15
rivet nuts have been positioned, and with (4)
6/100x20 screws in the case of throughbores
(when secured to the roof, introduce screws
of the cabin and secure on the inside using
will prevent water from entering the cabin).
5- Place nut caps on the inside of the cabin.
1
2
4
1
evaporator on the ceiling
4
4
5
EVAPORATOR
