Air conditioning for vehicles
COMPRESSOR MOTOR
1
2
2
2
2
CAUTION: THE COMPRESSOR MUST ALWAYS WORK
IN HORIZONTAL POSITION, NEVER VERTICALLY.
MAXIMUM SLANT 15º.
360º
Maximum 15°
1- Remove the compressor motor protection
frame, place in the position required for
installation, mark and make boreholes, and
secure with the screws supplied.
2- Connect the compressor motor electro wire
clamp and position the protection frame
using the supplied screws.
