dirna Bergstrom bycool SPLIT - CONDENSER; Piping and Cable Connection

SPLIT

EN
Air conditioning for vehicles
CONDENSER
PIPING AND CABLE CONNECTION
1 1
1- Position the condenser in the required
place, make the boreholes and secure with
the supplied screws.
1- Connect the pipes and cabling, passing
them through the most appropriate place
       
twisting.
Clamps and screws are supplied to secure
the cables and piping; make sure these are
protected with edgebands and sleeves.
Discard the excess cabling in an appropriate
place.
SEE CABLE AND PIPING CONNECTION
DIAGRAMS
