SLIM
EN
®
Original edgeband
Hexagon L=13 M4
Cabin roof
Upholstery
Fastening mount
Allen screw
6/100x15
Allen screw
6/100x15
Hexagon
M-F
Screw M8/125
Ø8 Flat washer
Grower washer
EXPLODED VIEW THROUGH TO FASTENING MOUNT
EXPLODED VIEW THROUGH TO CONSOLE FASTENING
