Dirna Mini cool compact - Page 18

18
INCLUDED PARTS
Id. Qty. Code nº Spare Parts
1 1 0910870007
Condenser
2 1 0910870070
Lower cover
3 1 1753010000
Electric fan
4 1 0910870111
Drainage tray
5 1 0910870006
Coil
6 2 0910870022
Compressor
7 2 0910560013
Electronic module
8 1 0910870032
Cover Gasket
9 1 3303030000
10 tting
10 1 3303050000
10 tting
11 1 3303040000
10 tting
12 1 3303060000
10 tting
12a 8 1705490000
Gasket o’ring 3/8
13 1 0910870071
Capillary
13a 1 0910870072
Capillary short
13b 4 1705480000
Gasket 1/4
14 2 0910870027
Modules wiring
15 1 0910870028
Electro wiring
16 2 0910240014
M6 knob
17 1 0910870003
Air inlet grid
18 1 0910870005
Outside cover
19 1 0910870029
Panel wiring
20 2 200TA10002
6/100x15 allen screws
20a 2 121290B000
White plastic cap
21 1 0910260007
Rear grid
22 7 200TR20077
Srew 6.3x19
23 1 1600520024
24V. pressuriser
24 1 0910870112
Waste water tray cover
25 7 1745780000
Fast nut
26 1 0910870025
Condenser insulant
27 1 0910870002
Base
28 1 0910100060
EPDM 30x25 joint
28a 1 0910100061
EPDM 30x15 joint
29 1 0910870017
console long
29a 1 0910870019
console short
29b 1 0910870016
console
30 1 0910870013
Electric control B
31 1 091016G061
Electronic cover
32 1 091010G005
Evaporator cooler front
33 4 1213070000
Circular air vent
Id. Qty. Code nº Spare Parts
34 4 202TR30005
Quick fastening
35 1 0910870014
Plate with serigraphy
36 1 0910160058
Adhesive with connectors
37 1 0910520036
Remote control B
38 2 091026G010
Short canalisation system
39 1 0910870023
Coil insulant
40 1 1745380000
Ø 22 ext. insulant
41 2 0910870015
Blower joint
42 4 0910260020
M6 stud, L=55
42a 4 0910260021
M6 stud, L=80
42b 4 0910260097
M6 stud, L=120
43 4 0910160013
M8 stud, L=120
43a
4
0910260023
M8 stud, L=100
43b
4
0910260024
M8 stud, L=70
44 1 0910520022
Temperature probe
45 1 0910870021
Base joint
46 2 1745220000
3/8 rubber grommet
47 1 1806880000
1/2 plastic clamp
47a 1 1806870000
3/8 plastic clamp
48 1 0910520023
Bag of nuts and bolts
49 2 0910870113
Drainage valve
50 4 1330440000
14 x M6 hexagonal separator
50a 4 0910260022
25 x M6 hexagonal separator
51 4 201AG10003
Ø20xØ7x3mm rubber washer
52 4 201AG10002
Ø18xØ6x3mm rubber washer
53 1 0910870036
Wiring for battery power supply
54 1 0910870046
Evaporative cover joint
55 1 1745570000
Ø16x15 clamp with rubber
56 2 0910100009
Fastening support
57 12 1797700000
Plastic fastening support
58 25 1745070001
200 x 4.8 white plastic ange
58a 20 1745090000
370 x 7.6 black plastic ange
59 1 1745740000
Angle irons with vertical frame
60 16 200TP41012
Ø 4.1x12 screw for plastic
60a 4 200TP40012
Ø 4.6x12 screw for plastic
60b 2 200TP41030
Ø 4.1x30 screw for plastic
