Preparatory work
Unpacking and assembling
ᆺCheck that the contents are complete (Fig. 1 ,
Fig. 2 for optional accessories). If you notice any
transport damage or if anything is missing, contact
your dealer immediately. ᆻConnect the appliance
(Fig. 1 /1) to the suction tube (Fig. 1 /2, Fig. 3 ) and
the lower connection piece of the suction tube by
inserting it into the stop catch on the oor nozzle
(Fig. 4 ) so that you hear and feel it click into place.
NOTE:
If you wish to detach the oor nozzle or the suc-
tion tube later, press in the release catch to dis-
engage the components from each other. Then,
pull the components apart.
NOTE:
Place the appliance in a corner of the wall, place
it at on the oor or insert the appliance into the
wall mount (Fig. 8 ) so that it does not topple
over.
Charging the rechargeable battery
WARNING!
Risk of re or explosion! Only use the mains
adapter included in the scope of supply to
charge the rechargeable battery.
ᆺConnect the mains adapter cable to the charging
socket on the appliance (Fig. 5 ). ᆻConnect the
mains adapter to a socket (Fig. 6 ). ᇄThe “ON/OFF”
LED lights up constantly in red to indicate the charg-
ing process (Fig. 7 ). ᆼAfter a maximum of
5.5 hours, the “ON/OFF” LED switches to green.
ᇄThe rechargeable battery is then charged.
ᆽDisconnect the mains adapter from the socket (to
save electricity) and disconnect the mains adapter
cable from the appliance.
Installing the wall mount
ᆺConnect the handle of the appliance to the wall
mount (Fig. 8 ). ᆻPlace the appliance against the
wall, together with the wall mount, so that the oor
nozzle rests at on the oor. ᆼMark the positions for
the drilled holes with a pencil.
ᆽDrill the holes. ᆾRemove the wall mount from the
handle and screw it to the wall with suitable fasten-
ing accessories. ᆿInsert the hole covers.
Switching the appliance on/o
NOTE:
When the“ON/OF” LED (Fig. 7 ) ashes red, the
rechargeable battery charge is low and the ap-
pliance will switch o within 20 seconds. Fully
charge the rechargeable battery to use the appli-
ance again > „Charging the rechargeable battery“
on page 17.
Ⴇ
To switch on the appliance, press and hold the
ON/OFF button on the handle (Fig. 9 /1).
Î The motor starts. “ON/OFF” LED lights up
green.
NOTE:
You can lock the ON/OFF button so that the
appliance remains switched on permanently
(Fig. 9 /2). Do not forget to release the locking
mechanism after cleaning.
Ⴇ
To switch o the appliance, release the ON/OFF
button (Fig. 9 /1).
Î The appliance switches o. The “ON/OFF” LED
goes out.
Vacuum-cleaning oors or furniture
ᆺFit one of the following nozzles as required if
included in the scope of supply:
NOTE:
The nozzles can also be attached directly to the
connection port on the base appliance.
(Fig. 10+19 ).
• Combo oor nozzle with rotating brush for option-
al activation for hard oors and carpets (Fig. 1 /3)
CAUTION!
Make sure that the surface can withstand the
rotating brush without becoming damaged.
• Parquet brush (gentle on oors) (Fig. 2/D )
• 3-in-1 combo nozzle (brush for joints, furniture &
upholstery) (Fig. 1/4 )
• Long exible crevice nozzle (Fig. 2/A )
• Extended exible furniture brush (Fig. 2/B )
ᆻSwitch on the appliance. ᆼVacuum-clean the oor
or the piece of furniture. ᆽActivate or deactivate the
rotating brush roller on the combo oor nozzle as re-
quired using the button on the top of the appliance
(Fig. 7 /1). ᆾSwitch o the appliance.
!
17
EN
