Maintaining the appliance
Removing the rechargeable battery
ᆺPress and hold the locking mechanism for the
rechargeable battery to release it. ᆻRemove the
rechargeable battery from the appliance (Fig. 12 ).
Emptying the dust bin
ᆺOpen the release catch on the connection port
to disconnect the base appliance from the suction
tube or the attached nozzles (Fig. 3 ). ᆻHold the
appliance with the dust bin over a waste bin. ᆼPress
the locking mechanism on the dust bin cover
(Fig. 13 ). ᇄThe dust bin cover opens downwards
and the dust falls out.
Cleaning the lter
NOTE:
The appliance and the lter should be cleaned
regularly in order to maintain the suction power.
ᆺPress the lter release button at the rear of the
appliance.ᆻPull the lter holder out of the appli-
ance (Fig. 14 ). ᆼRemove the lter from the mount
(Fig. 15 ). ᆽTap out the lter and the mount over a
waste bin. ᆾRinse out the lter under running water
(max. 40°C). ᆿLeave the lter to dry for at least 24
hours before you insert the lter and mount into the
appliance again.
Cleaning the cyclone unit
ᆺEmpty the dust bin, > „Emptying the dust bin“ on
page 18. ᆻPress and hold the dust bin release catch
on the underside of the appliance
(Fig. 16 /1). ᆼTip the dust bin towards the connec-
tion port for the suction tube and pull it downwards
(Fig. 16 ). ᆽTurn the lter eece anti-clockwise and
pull it downwards from the cyclone unit (Fig. 17 ).
ᆾTurn the cyclone unit anti-clockwise and pull it
downwards from the appliance (Fig. 18 ). ᆿTap out
the lter eece and the cyclone unit over a waste
bin. ᇀUse a dry cloth to remove any remaining dust
and dirt.
Inserting the cyclone unit
ᆺConnect the cyclone unit to the appliance so that
the two arrows on both components line up. ᆻTurn
the cyclone unit clockwise so that it clicks into place.
ᆼAttach the lter eece to the cyclone unit with the
seal facing away from the appliance. ᆽTurn the lter
eece clockwise to lock it in place. ᆾPlace the dust
bin on the appliance in a slightly inclined position.
ᆿPush the dust bin towards the handle to lock it in
place.
Removing and cleaning the brush roller
ᆺRelease oor nozzle as necessary and remove it
from the suction tube (Fig. 4 ). ᆻPush the brush
locking mechanism on the underside of the oor
nozzle to the side (Fig. 20 ). ᆼLift the brush roller
from the oor nozzle (Fig. 21 ). ᆽRemove any dirt
and hairs from the oor nozzle and from the brush
roller. If necessary, you can carefully use a pair of
scissors as an aid.
Accessories
• Hygienic exhaust lter - 0698002 (Fig. 22 /A )
• Brush roller- 0698413 (Fig. 22 /B )
• Separator with lter - 0698401 (Fig. 22 /C )
• Dust bin assembly - 0698405 (Fig. 22 /D )
• Wall mount - 0698011 (Fig. 22 /E )
• Mains adapter - 0698003 (Fig. 22 /F )
• Rechargeable battery - 0698004 (Fig. 22 /G )
Troubleshooting
Before you contact our customer service department
or send the appliance to the Dirt Devil customer
service department, you will nd a lot of additional
information in the service area of our website which
will help you solve problems:
www.dirtdevil.de/service
WARNING!
Switch o the appliance before you start trou-
bleshooting. Never use a faulty appliance, mains
adapter or rechargeable battery.
!
EN
18
