UNIT SET-UP
ADDING DEVICE
NETWORK CONNECTION
u
Before setting up, have your home Wi-Fi network
password ready and make sure your network
meets the following requirements:
• The Wi-Fi router supports 802.11b/g/n
and IPv4 protocols
• EV3320 vacuum cleaner ONLY
supports 2.4GHz frequency band,
it does not support the 5GHz frequency band
INITIAL Wi-Fi SETUP
v
When the lights on the unit begin to ash,
Select “Conrm the indicator
is ashing slowly”
Then click “NEXT”
NEXT
Pairing the Robot
• Press and hold the “ ” and “ ” buttons
at the same time for 3 seconds
•Listen for “BEEP”
• Conrm the indicator lights ash slowly
Conrm the indicator lights ash slowly
A
B
NOTE: as the robot vacuum enters the
PAIRING STATUS, you can see both
buttons ashing slowly in white as an
indicator that the unit is in pairing mode.
NOTE: If the vacuum cleaner cannot be
connected in a 2.4/5GHz dual-band Wi-Fi
network, make sure to select the 2.4GHz
network for Wi-Fi Setting prior to pairing
the unit with your home network.
After initial setup you can switch back
to 5GHz frequency band for other devices.
A
B
• Light ashes SLOWLY: in pairing
mode, waiting for connection
•Light ashes QUICKLY:
connection to Wi-Fi in progress
•White light is normally ON:
Wi-Fi is connected successfully
EV3320
Wi-Fi Conguration Help
First press the “ ” for 3 seconds to turn on
the unit, then press and hold the “ ” and “ ”
button at the same time for 3 seconds on the
unit, until you hear an audio “Beep”.
