13
Battery Type:
Lithium-Ion battery
Battery Capacity: 2600mAh
Dust Bin Capacity: 800ml
Operating Time: 100 minutes (Std. mode)
Suction Power: 4,000 Pa
Sound level: 70dBA (Std. mode)
Charging Time: 4.5 - 5.5 hours
Rated Voltage: 14.4V
Rated Power: 45W
Rated Input: 19V 0.6A
POWER ADAPTER:
Input voltage: 100-240V~50/60Hz
Rated Output: 19V 0.6A
Technical Specifications
Unit Dimensions (WDH):
13.6“ x 13.6” x 3.75” (345x345x95mm)
Weight: 6.3 lbs. (2.87kg)
CLEAN UNIVERSAL WHEEL
Hair or dust particles tend to be entangled around
wheels. Clean the them regularly or as needed.
Pull up wheels to take them out.
Clean any hair or debris entangled around
wheels, or in any caster chamber.
Reinstall wheels and push them in till they
click into place.
CLEAN ROBOT SENSORS
Please clean sensors regularly, and wipe dust off
them with a soft dry cloth or sweep brush.
CLEAN THE CHARGING DOCK
In order to ensure optimum operating conditions,
please clean charging electrode regularly, and wipe
dust off them with a soft dry cloth or sweep brush.
MAINTENANCE
u
v
w
Charging Electrodes
Robot Vacuum
Charging Electrodes
Anti-drop Sensors
Lidar Sensor
Recharge
Sensors
FOR SERVICE TECHNICIANS ONLY
• Press the front bumper of the robot
vacuum rst to ensure that Sensors are
triggered, and then press and hold the
“ ” button for 10-15 seconds, until
the LED turns off, and it will enter the
Energy Saving Mode.
• In this mode, only the charging feature will
work, other function will not work, such as
LEDs will be off, sensors will be disabled,
and Wi-Fi will be disconnected.
• To EXIT Energy Saving Mode, press the
“ ” button on the robot vacuum,
it will restart automatically and resume
normal operation.
