Base Assembly
Parts List (Base Package)
PART QUANTITY
A: User Manual ..........................................................................................................................................1
B: Metal Base .............................................................................................................................................1
C1: Lower Tubing (Left) ............................................................................................................................1
C2: Lower Tubing (Right) ...........................................................................................................................1
D1: Upper Tubing (Left) .............................................................................................................................1
D2: Upper Tubing (Right) .........................................................................................................................4
E: Tubing Connector .................................................................................................................................2
F: Pan Head Screw .................................................................................................................................. 12
*Hex Wrench for Part F can be found inside the TV Bracket box. (DUOPOLEBK, DUOPOLESL)
If you have any questions regarding our products, please visit us at www.displays2go.com or
contact Displays2go customer service at 844-221-3388.
CAUTION: Heavy metal base can cause muscle strain or back injury! Two people required for
assembling and moving unit.
