5
4. Secure lower tubings to base using
screws (F). Tighten with hex wrench.
Place Lower Tubings
Fasten Lower Tubings
F
B
C1
C2
2. Carefully place the metal base (B) on
hard, flat ground.
3. Insert left and right lower tubings (C)
into the left and right upright slot on
the metal base. Holes at top of lower
tubings should face outward to align
with the holes of tubing connectors later
in assembly.
To Next Page
