30 750/752 Tracker - OPERATION
BEACON TRACKING MODES
30 750/752 Tracker - OPERATION
BEACON TRACKING MODES
Remote Guidance Mode
Information is transmitted directly to display at drilling unit when
tracker is in remote guidance mode. Approximate distance from
tracker to beacon (not the estimated depth of the drill head) is
shown every 5 seconds.
Distance will not be correct within one and a half times the drill
head depth. For example, if you are drilling at 4’(1.2 m), you will
be able to drill within 6’ (1.8 m) of tracker.
To operate in remote guidance mode, place unit in stand while it
is turned off. Press and hold mode button while pressing on/off
button.
Tracker and drill head can be up to 60’ (18.3 m) apart when in
remote guidance mode. IMPORTANT: Do not drill past tracker.
Remote Guidance Mode
Information is transmitted directly to display at drilling unit when
tracker is in remote guidance mode. Approximate distance from
tracker to beacon (not the estimated depth of the drill head) is
shown every 5 seconds.
Distance will not be correct within one and a half times the drill
head depth. For example, if you are drilling at 4’(1.2 m), you will
be able to drill within 6’ (1.8 m) of tracker.
To operate in remote guidance mode, place unit in stand while it
is turned off. Press and hold mode button while pressing on/off
button.
Tracker and drill head can be up to 60’ (18.3 m) apart when in
remote guidance mode. IMPORTANT: Do not drill past tracker.
