FX20 Operator’s Manual Specifications - 85
CMW
Specifications are called out according to SAE recommended practices. Specifications are general and
subject to change without notice. If exact measurements are required, equipment should be weighed and
measured. Due to selected options, delivered equipment may not match that shown.
Trailer - S4S U.S. Metric
Dimensions
Adj. coupler height 16 in 406 mm
Width between fenders 64 in 2.2 m
Width outside fenders 86 in 2.2 m
General
Number of axles 2
Coupler (bolt-on adjustable) 2”, 2 5/16”, 3” lunette
Type of brakes electric
Lug nut torque 95 ft•lb 129 N•m
Hitch bolt torque 160 ft•lb 217 N•m
Electrical system 12V DC
Tire
ST225/75R15 load range D 65 psi 4.5 bar
Load rating
Tongue weight (empty) 406 lb 184 kg
Tongue weight (full water) 563 lb 255 kg
Max tongue load 1500 lb 680 kg
GVWR (gross vehicle weight rating) 4500 lb 2041 kg
GAWR (gross axle weight rating) 4500 lb 2041 kg
Load ratings for speeds up to 65 mph (104 km/h).
