RT80Q Operator’s Manual Backhoe - 119
Operation
CMW
Operation
Dig
Use boom/swing control and bucket/dipper control to dig hole or trench.
• Keep dipper and boom at right angles as
much as possible for maximum power.
• Keep bucket in line with dipper as much
as possible.
• Position bucket so teeth cut soil. As soil is
cut, curl bucket under dipper.
• Move dipper and bucket together.
Increasing engine speed will not increase
backhoe force.
Move Unit
To move unit from the backhoe operator’s
station using the remote ground drive function:
1. Raise stabilizers.
2. Use remote ground drive switch to move unit.
3. Lower stabilizers.
IMPORTANT: For more information about backhoe controls, see “Backhoe Console” on page 60.
NOTICE:
• Remote ground drive is disabled if an
operator is sitting in main operator seat.
• Remote ground drive is disabled if
ground drive controls are not in neutral.
• Only use this method to move unit less
than 30’ (10 m) at one time.
