RT80Q Operator’s Manual Specifications - 201
A820 Backhoe
A820 Backhoe
Dimensions U.S. Metric
A Transport height 113.5 in 2.9 m
C Ground clearance 36.6 in 929 mm
D Backhoe length, stowed 57.2 in 1.5 m
F Digging depth, max. 89 in 2.2 m
G Digging depth, 2” (0.6 m) flat bottom 88.2 in 2.2 m
J Operating height, fully raised 152.2 in 3.9 m
K Loading height 94.2 in 2.4 m
L Loading reach 56.1 in 1.4 m
M Reach from swing pivot 142.2 in 3.6 m
N Swing pivot to centerline axle 40.1 in 1.0 m
P Bucket rotation 150° 150°
B Stabilizer spread, transport 67.6 in 1.7 m
