RT80Q Operator’s Manual Controls - 25
Center Console
CMW
10. Ground drive speed
switch
To select High (3), Medium
(2) or Low (1), press
appropriate switch position.
Screen icon displays High, Medium or
Low selection.
11. Ignition switch To start engine, insert key and
turn clockwise.
To stop engine, turn
counterclockwise.
IMPORTANT: If engine does not start
on first attempt, check that all
interlock requirements have been
met, return switch to STOP, and try
again.
12. Ground drive foot
control
To move tractor forward, push
top of pedal.
To move tractor backward,
push bottom of pedal.
To increase speed in either
direction, push pedal farther
from center.
To reduce speed in either
direction, release pedal.
Pedal should automatically return to
neutral when released.
Item Description Notes
c00ic602w.eps
3
2
1
c00ic217h.eps
c00ic072c.eps
