Assembly
Handle and Base Plate Mounting Bracket Assembly (continued)
Insert lower handle (E) into guide holes
and slide into place. (Figure 3)
Insert base plate support bar (F) into
guide holes and slide into place. (Figure 4)
9
Make sure base plate support bar
has the bracket mounting hole
facing up and away from the lower
handle.
2
3
Figure 3
Figure 4
F
To Next Page
