5
Assembly
Handle and Base Plate Mounting Bracket Assembly (continued)
Position body (A) onto its side keeping
the lower handle and base plate
support bar in place. (Figure 5)
Repeat step 5 for the nal three threaded bolts of the lower handle (E) and base plate support bar (F).
6
Position body (A) back onto its wheels.
7
4
Figure 5
Slide washer (N), locking washer (R)
onto one of the four threaded bolts
of the lower handle (E) and base plate
support bar (F). Then insert nut (O) into
the hand tool (S). Use hand tool (S) to
fully tighten. (Figure 6)
5
Figure 6
To Next Page
