dji A3 User Manual

A3/A3Pro
User Manual
26
©
2016 DJI. All Rights Reserved.
GPS Signal Weak Slowly Blinking Yellow
Flight Limits DJI GO app Aircraft Status Indicator
Maximum
Flight
Altitude
Height is restricted to 400
feet. (120m) and under.
Warning: Height limit
reached.
None.
Max
Radius
No limits
If the aircraft ies out of the limit, you can still control the aircraft, but you cannot y it
any farther.
If the aircraft ies out of the max radius it will y back within range automatically when
GPS signal is strong.
No-Fly Zones
All No-Fly Zones are listed on the DJI official website at http://www.dji.com/flysafe/no-fly. No-
Fly Zones are divided into Airports and Restricted Areas. Airports include major airports and
ying elds where manned aircraft operate at low altitudes. Restricted Areas include border lines
between countries or sensitive institute. The details of the No-Fly Zones are explained as follow:
Airport
(1) Airport No-Fly Zone are comprised of Take-o Restricted zones and Restricted Altitude Zones.
Each zone features circles of various sizes.
(2) R1 miles (value of the R1 depends on the size and shape of the airport) around the airport is a
Take-o restricted zone, inside of which take o is prevented.
(3) From R1 mile to R1 + 1 mile around the airport the flight altitude is limited to a 15 degree
inclination.Starting at 65 feet (20 meters) from the edge of airport and radiating outward. The
ight altitude is limited to 1640 feet (500 meters) at R1+1 mile
(4) When the aircraft enters within 320 feet (100 meters) of No-Fly Zones, a warning message will
appear on the DJI GO app.

dji A3 Specifications

Flight Performance

hovering accuracy (vertical)	±0.5 m
hovering accuracy (horizontal)	±2 m
max wind resistance	10 m/s
max yaw angular velocity	150°/s
max pitch angle	35°
max ascent velocity	6 m/s
max descent velocity	6 m/s

Power and Environment

power consumption	Max 21 W (Typical Value: 0.41 A @ 51 V)
operating temperature	14° to 113° F (-10° to 45° C)
