dji A3 User Manual

A3/A3Pro
User Manual
28
©
2016 DJI. All Rights Reserved.
GPS Signal Strong Blinking Green
Zone Restriction DJI GO app Prompt
Aircraft Status
Indicator
No-y Zone
Motors will not start.
Warning: You are in a
No-fly zone. Take off
prohibited.
Red ashing
If the aircraft enters the
restricted area in A-mode,
but is switched to P-mode,
the aircraft will automatically
descend, land, and stop its
motors.
Warning: You are in a no-
y zone. Automatic landing
has begun.
Restricted-
altitude ight
zone
If the aircraft enters the
restricted area in A-mode, but
is switched to P-mode, it will
descend to an appropriate
altitude and hover 15 feet
below the altitude limit.
R1: Warning: You are
in a restricted zone.
Descending to safe
altitude.
R2: Warning: You are in a
restricted zone. Maximum
ight altitude is restricted
to between 20m and
500m. Fly cautiously.
Warning zone
No flight restriction applies,
but there will be a warning .
Warning: You are
approaching a restricted
zone, Fly cautiously.
Free zone
No restrictions. None. None.
Semi-automatic descent: All stick commands are available except the left stick command
during the descent and landing process. Motors will stop automatically after landing.
When flying in a safety zone, the aircraft's status indicator will blink red rapidly and
continue for 3 seconds, then switch to indicate current ying status and continue for 5
seconds at which point it will switch back to blinking red.
For safety reasons, please do not y close to airports, highways, railway stations, railway
lines, city centers, or other sensitive areas. Fly the aircraft only within your line of sight.

dji A3 Specifications

Flight Performance

hovering accuracy (vertical)	±0.5 m
hovering accuracy (horizontal)	±2 m
max wind resistance	10 m/s
max yaw angular velocity	150°/s
max pitch angle	35°
max ascent velocity	6 m/s
max descent velocity	6 m/s

Power and Environment

power consumption	Max 21 W (Typical Value: 0.41 A @ 51 V)
operating temperature	14° to 113° F (-10° to 45° C)
