dji A3 User Manual

A3/A3Pro
User Manual
©
2016 DJI. All Rights Reserved.
37
Peripheral
Supported Airframes
4-rotor: I4, X4
6-rotor: I6, V6, Y6, IY6
8-rotor: X8, I8, V8
Supported ESC output 400 Hz refresh frequency
Supported Receivers
DJI Lightbridge 2
DJI DR16
S-Bus
Recommended Batteries
DJI Intelligent Flight Battery
3S-12S LiPo battery
Required Operation System
Windows 7, 8 or 10 (32 or 64 bit)
Mac OS X 10.9 or later
SDK
Mobile SDK
Onboard SDK
Onboard SDK Ports API, CAN2*
Expansion Ports
F1-F4 ports for output
F5-F8 ports for I/O*
Electrical & Mechanical
Rated Power
A3: 5 W
A3 Pro: 10 W
Rated Peak Power
A3: 8 W
A3 Pro: 16 W
Input Voltage Range 10.5 – 52 V
Static Electricity
AD: ±8 kV
CD: ±4 kV
Operating Temperature 14° to 113° F (-10° to 45° C)
Weight
Flight Controller: 66 g
GPS-Compass Pro: 60 g
LED Module: 15 g
IMU Pro: 40 g
PMU: 45 g
*Coming soon.

dji A3 Specifications

Flight Performance

hovering accuracy (vertical)	±0.5 m
hovering accuracy (horizontal)	±2 m
max wind resistance	10 m/s
max yaw angular velocity	150°/s
max pitch angle	35°
max ascent velocity	6 m/s
max descent velocity	6 m/s

Power and Environment

power consumption	Max 21 W (Typical Value: 0.41 A @ 51 V)
operating temperature	14° to 113° F (-10° to 45° C)
