Aircraft
The Agras T40 has a truss-style design with arms that can be folded to reduce the body size, making the
aircraft easier to transport. The all-new integrated spraying system can quickly be swapped with a spreading
system with a spreading payload of up to 50 kg.
The spatial intelligent sensing system includes active phased array radars and binocular vision to ensure ight
safety. Boasting a 12MP UHD FPV camera with a tiltable gimbal, the aircraft can automatically collect HD eld
images for local oine reconstruction to assist in precise eld planning. Using the P4 Multispectral and DJI
Agras Intelligent Cloud, prescription maps can be generated in order to perform variable rate fertilization.
The coaxial twin rotor structure produces strong winds so that pesticides are able to penetrate thick canopies
for thorough spraying. The spraying system is equipped with the brand new magnetic drive impeller pumps,
dual atomized sprinklers, and anti-drip centrifugal valves. When used with the weight sensors, the spraying
system provides real-time liquid level detection and improves spraying eciency while saving liquid pesticide.
Core modules adopt potting technology and the aircraft has a protection rating of IPX6K (ISO 20653:2013) so
that the aircraft body can be washed directly with water.
1. Propellers
2. Motors
3. ESCs
4. Aircraft Front Indicators (on
two front arms)
5. Frame Arms
6. Folding Detection Sensors
(built-in)
7. Spray Lance
8. Sprinklers
9. Spray Tank
10. Delivery Pumps
11. FPV Camera
12. Binocular Vision System
13. Spotlights
14. Heat Sinks
15. Active Phased Array
Omnidirectional Radar
16. Active Phased Array Backward
and Downward Radar
17. Intelligent Flight Battery
18. Landing Gear
19. OCUSYNC
TM
Transmission Antennas
20. Onboard D-RTK
TM
Antennas
21. Aircraft Rear Indicators (on two
rear arms)
FoldedRear View
16
4
2
3
5
6
7
9
1
18
15
21
14
13
10
19
11
12
17
8
20
