dji AGRAS T40

EN
15
Specications
Aircraft
Model 3WWDZ-40A
Weight 38 kg (excl. battery)
50 kg (inc. battery)
Max Takeo Weight
[1]
Max takeo weight for spraying: 90 kg (at sea level)
Max takeo weight for spreading: 101 kg (at sea level)
Max Diagonal Wheelbase 2,184 mm
Dimensions 2,800×3,150×780 mm (arms and propellers unfolded)
1,590×1,930×780 mm (arms unfolded and propellers folded)
1,125×750×850 mm (arms and propellers folded)
Hovering Accuracy Range (with
strong GNSS signal)
D-RTK enabled: Horizontal: ±10 cm, Vertical: ±10 cm
D-RTK disabled:
Horizontal: ±60 cm, Vertical: ±30 cm (radar module enabled: ±10 cm)
Operating Frequency
[2]
2.4000-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz: <20 dBm (SRRC/CE/MIC), <33 dBm (FCC)
5.8 GHz: <33 dBm (SRRC/FCC), <14 dBm (CE)
RTK/GNSS Operating
Frequency
GPS L1/L2, GLONASS F1/F2, BeiDou B1/B2, Galileo E1/E5
GNSS: GPS L1, GLONASS F1, Galileo E1, BeiDou B1
Hovering Time
[3]
No payload: 18 min (takeo weight of 50 kg with a 30000 mAh battery)
Fully loaded for spraying: 7 min (takeo weight of 90 kg with a 30000 mAh
battery)
Fully loaded for spreading: 6 min (takeo weight of 101 kg with a 30000 mAh
battery)
Max Congurable Flight Radius 2,000 m
Max Wind Resistance 6 m/s
Operating Temperature 0° to 45° C (32° to 113° F)
Propulsion System
Motors
Stator Size 100×33 mm
KV 48 rpm/V
Power 4000 W/rotor
Propellers
Diameter 54 in (1371.6 mm)
Rotors Quantity 8
Dual Atomized Spraying System
Spray Tank
Volume Full: 40 L
Operating Payload
[1]
Full: 40 kg
Sprinklers
Model LX8060SZ
Quantity 2
Droplet Size 50-300 μm
Max Eective Spray Width
[4]
11 m (at a height of 2.5 m above the crops with a ight speed of 7 m/s)
Delivery Pumps
Type Magnetic drive impeller pump
Max Flow Rate 6 L/min × 2
