EN
17
Charging Type It is recommended to use a locally certied USB-C charger at a maximum rated
power of 65 W and maximum voltage of 20 V such as the DJI 65W Portable
Charger.
Charging Time 2 hours for internal battery or internal and external battery (when remote
controller is powered o and using a standard DJI charger)
O3 Agras
Operating Frequency
[2]
2.4000-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <23 dBm (SRRC)
Max Transmission Distance 7 km (FCC), 5 km (SRRC), 4 km (MIC/CE)
(unobstructed, free of interference, and at an altitude of 2.5 m)
Wi-Fi
Protocol WiFi 6
Operating Frequency
[2]
2.4000-2.4835 GHz, 5.150-5.250 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)
Bluetooth
Protocol Bluetooth 5.1
Operating Frequency 2.4000-2.4835 GHz
Transmitter Power (EIRP) <10 dBm
[1] The DJI Agras app will intelligently recommend the payload weight limit for the spread tank according to the current status and
surroundings of the aircraft. Do not exceed the recommended payload weight limit when adding material to the spread tank.
Otherwise, the ight safety may be aected.
[2] 5.8 and 5.1 GHz frequencies are prohibited in some countries. In some countries, the 5.1 GHz frequency is only allowed for
use indoors.
[3] Hovering time acquired at sea level with wind speed lower than 3 m/s and a temperature of 25° C (77° F). For reference only.
The data may vary depending on the environment. Actual results shall be as tested.
[4] The spray width depends on the actual operation scenarios.
[5] The eective sensing range varies depending on the material, position, shape, and other properties of the obstacle.
Download the
user manual for more information:
https://www.dji.com/t40/downloads
