dji AVATA 2 User Manual

DJI Avata 2 User Manual
©
2024 DJI All Rights Reserved.
45
once to cancel RTH. After exiting RTH, users will regain control of the aircraft.
Aircraft low battery
When the battery level is low and only sucient to y to the Home Point, a warning prompt
will appear in the goggles and RTH will be triggered following the prompt. RTH can be canceled
using the remote control devices. If RTH is canceled following a low battery warning, the
Intelligent Flight Battery may not have enough power for the aircraft to land safely, which may
lead to the aircraft being crashed or lost.
The aircraft will land automatically if the current battery level can only support the aircraft long
enough to descend from its current altitude. Auto landing cannot be canceled, but the remote
control devices can be used to control the horizontal movement of the aircraft during landing.
Loss of remote control or video transmission signal
When the remote control signal or video transmission signal is lost, the aircraft will
automatically initiate Failsafe RTH if the Signal Lost Action is set to RTH.
The aircraft will fly backwards 50 m along its original flight route and then perform the RTH
procedure. The aircraft will directly perform the RTH procedure if the signal is restored when
ying backward along the original ight route.
• The response of the aircraft when the wireless signal is lost can be modied in the
goggles. The aircraft will not perform Failsafe RTH if land or hover has been selected
in the settings.
RTH Procedure
1. The Home Point is recorded.
2. RTH is triggered.
3. When RTH begins, the RTH procedure varies according to different RTH distances (the
horizontal distance between the aircraft and the Home Point):
a. The aircraft lands immediately if the RTH distance is less than 5 m.
b. If the RTH distance is farther than 5 m but less than 20 m, it ies to the Home Point in a
straight line at the current altitude.
c. If RTH distance is farther than 20 m, it ascends to the RTH altitude and ies back to the
Home Point. The aircraft ies to the Home Point at the current altitude if the RTH altitude
is lower than the current altitude.
4. The aircraft begins to land when it reaches the spot above the Home Point.
Landing Protection
Landing Protection activates during RTH and auto landing.
1. During Landing Protection, the aircraft will automatically detect and carefully land on
suitable ground.
2. If the ground is determined unsuitable for landing, the aircraft will hover and wait for pilot
conrmation.

dji AVATA 2 Specifications

General

Type	Quadcopter
Product color	Black
Construction type	Ready-to-fly (RTF)
Suitable for outdoor use	Yes
Maximum speed	27 m/s
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.0
Maximum flight time	23 min
Maximum flight altitude	5000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Horizontal hover accuracy	0.3 m
Maximum operating distance	13000 m
Megapixel	12 MP
Video color modes	D-Log, Normal
Video resolutions	1440 x 1080, 1920 x 1080, 2688 x 1512, 2688 x 2016, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	Video: 1/8000-1/30, Photo: 1/8000-1/50 s
Mechanical tilt range	-95 - 90 °
Normal focusing range	0.6 - ∞ m
Supported file systems	exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	JPEG
Maximum aperture number	2.8
Video formats supported	H.264, H.265, MP4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2880 pixels
Field of view (FOV) angle	155 °
Bitrate at maximum video resolution	130 Mbit/s
Built-in processor	-
Internal memory	46 GB
Operating frequency	2400 - 2483.5 MHz
Battery voltage	14.76 V
Battery capacity	2150 mAh
Antennas quantity	4
Operating temperature (T-T)	-10 - 40 °C
Equivalent Isotropically Radiated Power (EIRP)	10 dBmW
Package type	Box
Cables included	USB Type-C

Weight and Dimensions

Depth	212 mm
Width	185 mm
Height	64 mm
Weight	377 g
