LED Indicators Descriptions
Power Indicator
Solid green Powered on.
Battery Status LEDs
Solid green Charging completed
Blinks green Charging
Solid yellow Waiting for charging.
Blinks yellow Warming up before charging.
Blinks yellow twice Cooling down before charging.
Blinks yellow three times Cannot charge the battery due to very low temperature. Please charge the battery in the place of higher temperature.
Solid red Battery error.
Blinks red * Battery communication warning, please try other battery ports.
Blinks red twice Battery short circuit, please try other battery ports.
Warning LED
Blinks yellow Battery Station is updating.
Solid yellow The input voltage is too low. Please use the power supply that meets the requirements.
Blinks red Power module communication error or other. *
Blinks red twice Motherboard error. *
Blinks red three times Fan error. *
Blinks red four times Battery Station self-test error. *
For errors marked with the after-sales team. *, please contact your local dealer or a representative from the DJI
Buzzer Beeping Description
Buzzer beeping is used to indicate errors as outlined below.
1. When the Battery Status LED is red, the buzzer is beeping to indicate a battery error.
2. When the Warning LED is red, the buzzer is beeping to indicate a Battery Station hardware error.
Specifications
Model BS60
Dimensions 501 × 403 × 252 mm
Net Weight 8.37 kg
Max Internal Load 12 kg
Compatible Stored Items TB60 Intelligent Flight Battery × 8 WB37 Intelligent Battery × 4 AC Power Cable
Input 100-120 Vac, 50-60 Hz / 220-240 Vac, 50-60 Hz
Output
TB60 Intelligent Flight Battery Port: 52.8 V, 7 A×2 @100-120 V, 8.9 A×2 @220-240 V
WB37 Intelligent Battery Port: 8.7 V, 6 A
Output Power 100-120 V, 750.0 W 220-240 V, 992.0 W
Power without Load < 8 W
Warming up the battery 52.8 V, 2 A
Operating Temperature -20 to 40 (-4° F to 104° F)
Charging Time* 100-120 V, 70 min 220-240 V, 60 min
Protection Features
Anti-backflow Protection Short Circuit Protection Over Voltage Protection Over Current
Protection Temperature Protection
* Charging times are tested in a lab environment at room temperature. The values provided should be used for reference only.
Compliance Information
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Supplier’s Declaration of Conformity
Product name: 8560 Intelligent Battery Station
Model Number. 8560
Manufacturer’s Name: SZ DJI TECHNOLOGY CO., LTD.
Manufacturer’s Address: 14th floor; West Wing, Skyworth Semiconductor Design Building NO.18 Gaoxin South 4th Ave, Nanshan District, Shenzhen, Guangdong, China
Responsible Party: WI Technology, Inc.
Responsible Party Address: 201 S. Victory Blvd., Burbank, CA 91502
