• Fully charge and discharge the battery at least once every three months to ensure the
performance of the battery.
• If a battery has not been charged or discharged for five months or more, the battery
will no longer be covered by the warranty.
Specifications
Specifications
DB1560 Intelligent Flight Battery
(BAX702-30000mAh-52.22V)
DB800 Intelligent Flight Battery
(BAX702-15500mAh-52.22V)
Nominal Voltage 52.22 V
Battery Type Li-ion
Battery Chemical System LiNiMnCoO2
Discharge Rate 11.5C
Operating Temperature -5° to 45° C (23° to 113° F)
Charging Temperature 0° to 60° C (32° to 140° F)
Warranty Details 1,500 cycles or 12 months (whichever occurs first)
IP Rating IP54 + Board-level potting protection
Compatible Aircraft DJI Agras T50, T25, T40, T20P, T30 DJI Agras T25, T20P
Capacity 30000 mAh 15500 mAh
Energy 1567 Wh 809 Wh
Max Charging Power 9500 W 5400 W
Compatible Charging
Device
[1]
D12000iEP Multifunctional Inverter
Generator
C10000 Intelligent Charger
D12000iE Multifunctional Inverter
Generator
[2]
C8000 Intelligent Battery Station
[2]
T40 Intelligent Charger
[2]
T30 Intelligent Battery Station
[2]
D9000i Multifunctional Inverter
Generator
[2]
D6000i Multifunctional Inverter
Generator
[2]
C8000 Intelligent Battery Station
[2]
D9000i Multifunctional Inverter
Generator
[2]
T30 Intelligent Battery Station
[2]
Charging Time for Each
Battery
[3]
Using the D12000iEP Multifunctional
Inverter Generator: 9-12 min
Using the D6000i Multifunctional
Inverter Generator: 9-12 min
Weight Approx. 12.1 kg Approx. 6.6 kg
[1] Charging devices available for purchase vary by country or region. Consult your local dealers for
details.
[2] Firmware update is required to charge the DB1560/DB800 Intelligent Flight Battery.
[3] Charging time was tested in a lab environment at a temperature of 25° C (77° F). For reference
only.
