dji MATRICE 200

Matrice 200
The DJI
TM
MATRICE
TM
200 is a powerful system with world class agility and speed, two barometers and IMU modules each for maximum
reliability, and new, smart ight features that make capturing complex shots easy. The aircraft’s visual sensors enables enhanced
hovering precision even when ying indoors or in environments where GNSS is unavailable. The vehicle’s new airframe design improves
the Ingress Protection Rating to IP43 in accordance with the global IEC 60529 standard.
The Matrice 200’s mechanical design, along with quick-release landing gear and mounted folding arms, makes it easy to transport,
store, and prepare for ight. The Intelligent Flight Battery features upgraded battery cells and an advanced power management system.
The drone provides up to 27-minutes of ight with standard batteries and 38-minutes with optional batteries without payload*.
The Matrice 200 is compatible with many of DJI’s DGC2.0 connector gimbals.* This manual uses the DJI ZENMUSE
TM
Z30 as an
example to demonstrate the Matrice 200’s remarkable functions.
* Maximum run-time is tested in a lab environment. Performance may vary depending on local conditions.
Gimbal and optional batteries can be purchased separately from the ofcial DJI Online Store.
DO NOT disassemble the aircraft case, otherwise, it will not be covered by the warranty.
17
19
14
13
12
16
18
2
11
10
9
8
5
6
1
7
3
4
15
1. FPV Camera
2. Forward Vision System
3. DJI Gimbal Connector V2.0
(DGC2.0)
4. Gimbal and Camera Detach Button
5. Frame Arms
6. Motors
7. Propellers
8. ESC LEDs
9. Landing Gear
10. Upward Infrared Sensor
11. Aircraft Status Indicator
12. RC/Aircraft Link Button and
Indicator
13. USB Port
14. USB Mode Switch
15. Battery Remove Button
16. Intelligent Flight Batteries
17. Battery Level Indicators
18. Power Button
19. Downward Vision System
20. Micro SD Card Slot
20
Folded
